Sierra IP LED
A back lit LED panel in three different sizes to fit a lay-in modular ceiling. Ideal for clean rooms, laboratories and areas where an extra level of IP protection is required.
Features
– Uniform light distribution
– Average rated LED life: 54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Various sizes available
– Photobiological hazard: RG1
IP65 | LED | CLASS I | CE
A back lit LED panel in three different sizes to fit a lay-in modular ceiling. Ideal for clean rooms, laboratories and areas where an extra level of IP protection is required.
Features
– Uniform light distribution
– Average rated LED life: 54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Various sizes available
– Photobiological hazard: RG1
IP65 | LED | CLASS I | CE
A back lit LED panel in three different sizes to fit a lay-in modular ceiling. Ideal for clean rooms, laboratories and areas where an extra level of IP protection is required.
Features
– Uniform light distribution
– Average rated LED life: 54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Various sizes available
– Photobiological hazard: RG1
IP65 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
LED output: 6363 – 14480lm
Luminaire output: 4010 – 9560lm
Luminaire efficiency: 93lm/W
CRI: 83
Material
Body: Sheet steel
Finish: White
Diffuser: Opal polycarbonate
Mounting: Recessed Modular
Options
2 step MacAdam, CRI:90
Other lumen outputs available
SAS and Burgess-T ceiling version
Tuneable white
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | DIMENSIONS | STANDARD | DALI | EMERGENCY STANDARD | DALI |
|---|---|---|---|---|---|---|---|
| 43W | 3000K | 4170lm | 596 x 596 | 11001501 | 11001503 | 11001591 | 11001593 |
| 43W | 4000K | 4250lm | 596 x 596 | 11001601 | 11001603 | 11001691 | 11001693 |
| 43W | 3000K | 4010lm | 296 x 1196 | 11001701 | 11001703 | 11001791 | 11001793 |
| 43W | 4000K | 4090lm | 296 x 1196 | 11001801 | 11001803 | 11001891 | 11001893 |
| 100W | 3000K | 9380lm | 596 x 596 | 11001901 | 11001903 | 11001991 | 11001993 |
| 100W | 4000K | 9560lm | 596 x 596 | 11002001 | 11002003 | 11002091 | 11002093 |
