Bari Surface LED
A modern and highly efficient surface mounted LED downlight to suit a wide range of applications.
Features
– High efficiency, general purpose surface LED downlight
– Long average LED life: >54,000hrs LED life (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP44 | LED | CLASS I | CE
A modern and highly efficient surface mounted LED downlight to suit a wide range of applications.
Features
– High efficiency, general purpose surface LED downlight
– Long average LED life: >54,000hrs LED life (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP44 | LED | CLASS I | CE
A modern and highly efficient surface mounted LED downlight to suit a wide range of applications.
Features
– High efficiency, general purpose surface LED downlight
– Long average LED life: >54,000hrs LED life (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
IP44 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
LED output: 1600 – 3820lm
Luminaire output: 1140 – 2750lm
Luminaire efficiency: ≥98lm/W
CRI: >80
Material
Body: Die-cast aluminium
Finish: White/ Black/ Grey
Diffuser: Clear glass
Mounting: Surface
Options
3hr emergency
Other RAL colours on request
Microwave sensors for enhanced energy savings
IP65 version
Wall mounted version
Suspension kit
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | STANDARD WHITE | STANDARD BLACK | STANDARD GREY | DALI WHITE | DALI BLACK | DALI GREY |
|---|---|---|---|---|---|---|---|---|
| 10W | 3000K | 1140lm | 32700901 | 32701701 | 32702501 | 32700903 | 32701703 | 32702503 |
| 10W | 4000K | 1160lm | 32701001 | 32701801 | 32702601 | 32701003 | 32701803 | 32702603 |
| 15W | 3000K | 1560lm | 32701101 | 32701901 | 32702701 | 32701103 | 32701903 | 32702703 |
| 15W | 4000K | 1590lm | 32701201 | 32702001 | 32702801 | 32701203 | 32702003 | 32702803 |
| 19W | 3000K | 1990lm | 32701301 | 32702101 | 32702901 | 32701303 | 32702103 | 32702903 |
| 19W | 4000K | 2030lm | 32701401 | 32702201 | 32703001 | 32701403 | 32702203 | 32703003 |
| 28W | 3000K | 2690lm | 32701501 | 32702301 | 32703101 | 32701503 | 32702303 | 32703103 |
| 28W | 4000K | 2750lm | 32701601 | 32702401 | 32703201 | 32701603 | 32702403 | 32703203 |
