Phoenix LED
A versatile, energy efficient, IP65 LED wall mounted luminaire that provides direct or direct and indirect illumination.
Suitable for a wide range of architectural, commercial and residential applications.
Features
– Various lens options
– High resistance to UV and oxidation
– Average rated life: >50,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– Easy to install and maintain
IP65 | IK06 | LED | CLASS I | CE
A versatile, energy efficient, IP65 LED wall mounted luminaire that provides direct or direct and indirect illumination.
Suitable for a wide range of architectural, commercial and residential applications.
Features
– Various lens options
– High resistance to UV and oxidation
– Average rated life: >50,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– Easy to install and maintain
IP65 | IK06 | LED | CLASS I | CE
A versatile, energy efficient, IP65 LED wall mounted luminaire that provides direct or direct and indirect illumination.
Suitable for a wide range of architectural, commercial and residential applications.
Features
– Various lens options
– High resistance to UV and oxidation
– Average rated life: >50,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– Easy to install and maintain
IP65 | IK06 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
Distribution: Symmetric
LED output: 1092lm - 4440lm (DIR)/ 2×820lm – 2×2150lm (DI-IN)
Luminaire output: 936lm-3662lm (DIR) / 2x697lm-2x1820lm (DI-IN)
CRI: >85
Beam Angle: 38 degrees
Material
Body: Die-cast aluminium
Finish: Anthracite grey/ Light grey
Diffuser: 3mm soda lime tempered clear glass
External fixings: Stainless steel
Mounting: Wall
Wiring: Ø8/12mm cable entry
Options
DALI
Second cable entry
2700K
Other RAL finishes
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | DIMENSIONS | DISTRIBUTION | ANTHRACITE GREY | LIGHT GREY |
|---|---|---|---|---|---|---|
| 10W | 3000K | 936lm | 180 x 90 | DIRECT | 75700101 | 75700201 |
| 10W | 4000K | 1020lm | 180 x 90 | DIRECT | 75700301 | 75700401 |
| 2 x 7W | 3000K | 2 x 697lm | 180 x 90 | DIRECT / INDIRECT | 75700501 | 75700601 |
| 2 x 7W | 4000K | 2 x 748lm | 180 x 90 | DIRECT / INDIRECT | 75700701 | 75700801 |
| 32W | 3000K | 3182lm | 240 x 115 | DIRECT | 75700901 | 75701001 |
| 32W | 4000K | 3662lm | 240 x 115 | DIRECT | 75701101 | 75701201 |
| 2 x 17W | 3000K | 2 x 1763lm | 240 x 115 | DIRECT / INDIRECT | 75701301 | 75701401 |
| 2 x 17W | 4000K | 2 x 1820lm | 240 x 115 | DIRECT / INDIRECT | 75701501 | 75701601 |
