Mustang LED
A recessed lay-in modular LED luminaire providing soft, diffuse illumination with minimal glare. Suitable for offices, schools, libraries and other public areas.
Features
– Microprism diffuser
– Fully LG7 compliant
– Average rated LED life: >60,000 hours (L80/B10)
– High visual comfort – low glare
– High lumen efficiency: 100lm/W
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Photobiological hazard: RG0
IP20 | LED | CLASS I | CE
A recessed lay-in modular LED luminaire providing soft, diffuse illumination with minimal glare. Suitable for offices, schools, libraries and other public areas.
Features
– Microprism diffuser
– Fully LG7 compliant
– Average rated LED life: >60,000 hours (L80/B10)
– High visual comfort – low glare
– High lumen efficiency: 100lm/W
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Photobiological hazard: RG0
IP20 | LED | CLASS I | CE
A recessed lay-in modular LED luminaire providing soft, diffuse illumination with minimal glare. Suitable for offices, schools, libraries and other public areas.
Features
– Microprism diffuser
– Fully LG7 compliant
– Average rated LED life: >60,000 hours (L80/B10)
– High visual comfort – low glare
– High lumen efficiency: 100lm/W
– Optimum colour consistency – 3 step MacAdam ellipse tolerance
– Photobiological hazard: RG0
IP20 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
Emission: Direct and indirect
LED output: 5080 – 9424lm
Luminaire output: 3274 – 6074lm
Luminaire efficiency: 90lm/W
CRI: 80
UGR: 19
Material
Body: Sheet steel
Finish: White
Diffuser: Microprism TP(a)
Mounting: Recessed Modular
Options
2 step MacAdam, CRI>90
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | DIMENSION | STANDARD | DALI | EMERGENCY STANDARD | EMERGENCY DALI |
|---|---|---|---|---|---|---|---|
| 36W | 3000K | 3274lm | 593 x 593 | 13400101 | 13400103 | 13400191 | 13400193 |
| 36W | 4000K | 3589lm | 593 x 593 | 13400201 | 13400203 | 13400291 | 13400293 |
| 62W | 3000K | 5675lm | 593 x 593 | 13400301 | 13400303 | 13400391 | 13400303 |
| 62W | 4000K | 6074lm | 593 x 593 | 13400401 | 13400403 | 13400491 | 13400403 |
