Concrete Series Options |
---|
Technical Information |
---|
Specification
Suspension length: Max. 1200mm
Dimensions: Diameter: 110mm, height: 155mm/ Diameter: 150mm, height: 220mm/ Diameter: 190mm, height: 270mm
Lampholder: E27, max. 15W
Materials
Body: Concrete
Finish: Choice of 8 base colours: Natural/ Grey/ Anthracite/ Black/ Chocolate/ Green/ Blue/ Ochre
Cable suspension: Steel/ Brass/ Copper
Cable: Polyester, cotton, linen and brocade options. Standard: Black polyester braid unless stated.
Ceiling rose: Steel, single cable (other options available)
Options
Concrete ceiling rose
Triple shade configuration
Decorative metal layer
Product Codes |
---|
FINISH | DIMENSIONS | STEEL | BRASS | COPPER |
---|---|---|---|---|
Natural | Ø110 x 115 | 55100100 | 55100900 | 55101700 |
Grey | Ø110 x 115 | 55100200 | 55101000 | 55101800 |
Anthracite | Ø110 x 115 | 55100300 | 55101100 | 55101900 |
Black | Ø110 x 115 | 55100400 | 55101200 | 55102000 |
Chocolate | Ø110 x 115 | 55100500 | 55101300 | 55102100 |
Green | Ø110 x 115 | 55100600 | 55101400 | 55102200 |
Blue | Ø110 x 115 | 55100700 | 55101500 | 55102300 |
Ochre | Ø110 x 115 | 55100800 | 55101600 | 55102400 |
Natural | Ø150 x 220 | 55102500 | 55103300 | 55104100 |
Grey | Ø150 x 220 | 55102600 | 55103400 | 55104200 |
Anthracite | Ø150 x 220 | 55102700 | 55103500 | 55104300 |
Black | Ø150 x 220 | 55102800 | 55103600 | 55104400 |
Chocolate | Ø150 x 220 | 55102900 | 55103700 | 55104500 |
Green | Ø150 x 220 | 55103000 | 55103800 | 55104600 |
Blue | Ø150 x 220 | 55103100 | 55103900 | 55104700 |
Ochre | Ø150 x 220 | 55103200 | 55104000 | 55104800 |
Natural | Ø190 x 270 | 55104900 | 55105700 | 55106500 |
Grey | Ø190 x 270 | 55105000 | 55105800 | 55106600 |
Anthracite | Ø190 x 270 | 55105100 | 55105900 | 55106700 |
Black | Ø190 x 270 | 55105200 | 55106000 | 55106800 |
Chocolate | Ø190 x 270 | 55105300 | 55106100 | 55106900 |
Green | Ø190 x 270 | 55105400 | 55106200 | 55107000 |
Blue | Ø190 x 270 | 55105500 | 55106300 | 55107100 |
Ochre | Ø190 x 270 | 55105600 | 55106400 | 55107200 |
