Inca LED
A cost-effective, high performance LED bulkhead luminaire with an excellent luminous efficiency. Ideal for corridors, receptions, waiting rooms, bathrooms and store rooms.
Features
– Cost effective, general purpose bulkhead
– No spotting – even light distribution
– Long rated LED life: >54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP54 | IK10 | LED | CLASS I | CE
A cost-effective, high performance LED bulkhead luminaire with an excellent luminous efficiency. Ideal for corridors, receptions, waiting rooms, bathrooms and store rooms.
Features
– Cost effective, general purpose bulkhead
– No spotting – even light distribution
– Long rated LED life: >54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP54 | IK10 | LED | CLASS I | CE
A cost-effective, high performance LED bulkhead luminaire with an excellent luminous efficiency. Ideal for corridors, receptions, waiting rooms, bathrooms and store rooms.
Features
– Cost effective, general purpose bulkhead
– No spotting – even light distribution
– Long rated LED life: >54,000hrs (L80/B10)
– Optimum colour consistency – 3 step MacAdam chromaticity tolerance
– UV stabilised – no yellowing
IP54 | IK10 | LED | CLASS I | CE
| Technical Information |
|---|
Performance
Light source: LED
LED output: 2460 – 2540lm
Luminaire output: 2070 – 2130lm
Luminaire efficiency: ≥115lm/W
CRI: >80
Material
Body: Polycarbonate
Finish: White/ Grey
Diffuser: Opal polycarbonate
Mounting: Surface
Options
Microwave sensor for enhanced energy savings
Bluetooth enabled
Internal fuse and LS0H cable
| Product Codes |
|---|
| LAMP | COLOUR TEMP | DELIVERED LUMENS | FINISH | STANDARD | DALI | EMERGENCY STANDARD | EMERGENCY DALI |
|---|---|---|---|---|---|---|---|
| 16W | 3000K | 2070lm | White | 40903001 | 40903003 | 40903091 | 40903093 |
| 16W | 4000K | 2130lm | White | 40903101 | 40903103 | 40903191 | 40903193 |
| 16W | 3000K | 2070lm | Grey | 40903201 | 40903203 | 40903291 | 40903293 |
| 16W | 4000K | 2130lm | Grey | 40903301 | 40903303 | 40903391 | 40903393 |
